INNO3D GeForce RTX 5060 Twin X2 OC 8GB GDDR7 Graphics Card

Description

The INNO3D GeForce RTX 50 Series promises exceptional performance from these next-gen graphics cards powered by NVIDIA’s Blackwell Architecture.

The INNO3D GeForce RTX 50 Series promises exceptional performance from these next-gen graphics cards powered by Nvidia’s Blackwell architecture. The INNO3D GeForce RTX 5060 TWIN X2 OC is a compact powerhouse designed for space-conscious enthusiasts, featuring a sleek dual-slot design that seamlessly integrates into smaller form factor builds. The TWIN X2 OC doesn`t just set new standards in performance; it also captivates with its contemporary aesthetic. This GPU features 4,608 CUDA cores and 8GB GDDR7 memory with a 128-bit interface, and a boost clock of 2,527MHz providing ample power for high-resolution gaming and demanding applications. Redefining the balance between style, size, and raw power, this next-generation graphics card establishes itself as the new benchmark, seeking uncompromised visual excellence in a compact package.

GPU

Chipset Manufacturer NVIDIA
Chipset Model Name GeForce RTX
Chipset Model Number 5060
Chipset Additional Information Twin X2 OC
Base Chip Clock 2280 MHz
Boost Chip Clock 2527 MHz
Graphics Core CUDA
Number of Cores 3840
Memory

Memory Size 8192 MB
Memory Clock 28 Gbps
Memory Type GDDR7
Memory Width 128 bit
Memory Bandwidth 448 GB/s
Interfaces/Ports

Video Card Bus Type PCI Express
Video Card Bus Version 5.0 x8
HDMI Port 1 x HDMI 2.1b
DisplayPort 3 x DisplayPort 2.1b
Resolution

Multiple Monitor Support (Max) Yes (4)
Maximum Resolution 7680 x 4320
System Requirements

System Requirements 1 x PCI Express 5.0 x16 slot
Electrical

Power Connector 1 x 8-pin PCIe
Power Consumption 145 W
Recomended Power Supply 550 W
Physical

Form Factor Graphics Card
In The Box Graphics Card
Width 41 mm (Dual Slot)
Depth 250 mm
Height 116 mm
Warranty

Warranty 3 Years
